Kubernetes 控制器开发、镜像构建及部署实践

ccvgpt 2025-06-24 12:09:12 基础教程 3 ℃

引言

随着云计算的普及，Kubernetes（K8s）已经成为现代微服务架构的事实标准。Kubernetes 控制器（Controller）是其自动化运维的重要组成部分，负责监听集群中的资源变化，并执行相应的操作。掌握 Kubernetes 控制器的开发，不仅能提升系统的可扩展性，还能帮助工程师深入理解 Kubernetes 生态。

本文将从零开始，带你完整体验 Kubernetes 控制器的开发、镜像构建和部署过程，帮助你快速上手并应用到实际生产环境。阅读本篇文章你将学到：

如何使用 kubebuilder 初始化 Kubernetes 控制器项目
编写核心控制逻辑，实现自定义资源管理
进行本地调试、监控并优化控制器的性能
构建 Docker 镜像并推送至镜像仓库
使用 Helm 进行部署与管理

一、初始化项目

$ go version
go version go1.23.0 linux/amd64
$ mkdir lb-layer7
$ cd lb-layer7/
$ go mod init lb-layer7
...
$ kubebuilder version
Version: main.version{KubeBuilderVersion:"4.2.0", KubernetesVendor:"1.31.0", GitCommit:"c7cde5172dc8271267dbf2899e65ef6f9d30f91e", BuildDate:"2024-08-17T09:41:45Z", GoOs:"linux", GoArch:"amd64"}
$ kubebuilder init --domain k8s.qihoo.net
...

//不创建resource，使用标准ingress资源
$ kubebuilder create api --group network --version v1alpha1 --kind Ingress
INFO Create Resource [y/n]
n
INFO Create Controller [y/n]
y

二、核心代码编写

cmd/main.go

// 注意端口: 通过 flag 定义的 metricsAddr 是 controller-runtime 框架自带的 metrics 服务
flag.StringVar(&metricsAddr, "metrics-bind-address", ":8888", "The address the metrics endpoint binds to. "+
  "Use :8443 for HTTPS or :8080 for HTTP, or leave as 0 to disable the metrics service.")
      // 测试环境调试可以将该值设置为false，这样curl http://localhost:8888/metrics 才有结果
flag.BoolVar(&secureMetrics, "metrics-secure", false,
  "If set, the metrics endpoint is served securely via HTTPS. Use --metrics-secure=false to use HTTP instead.")
// 初始化 metrics
metrics.InitMetrics()
if err = (&controller.IngressReconciler{
  Client:   mgr.GetClient(),
  Scheme:   mgr.GetScheme(),
  Recorder: mgr.GetEventRecorderFor("Layer7Reconciler"),
}).SetupWithManager(mgr); err != nil {
  setupLog.Error(err, "unable to create controller", "controller", "Ingress")
  os.Exit(1)
}

lb-layer7/internal/controller/ingress_controller.go

type IngressReconciler struct {
	client.Client
	Scheme       *runtime.Scheme
	layer7Client *k8scloud.Layer7
	Recorder     record.EventRecorder
}

func (r *IngressReconciler) Reconcile(ctx context.Context, req ctrl.Request) (ctrl.Result, error) {
	log := log.FromContext(ctx)
	log.Info("reconcile starting ...")

	// 更新调试计数器并验证
	metrics.ReconcileTotal.WithLabelValues(metrics.Reconcile).Inc()

	startTime := time.Now()
	defer func() {
		// 记录调谐时间
		metrics.ReconcileDealTime.WithLabelValues(
			req.Namespace,
			req.Name,
		).Observe(utils.GetElapsedTime(startTime))
		log.Info("Reconcile done", "ElapsedTime", utils.GetElapsedTime(startTime))
	}()

	ingress := &networkingv1.Ingress{}
	if err := r.Get(ctx, req.NamespacedName, ingress); err != nil {
		if errors.IsNotFound(err) {
			return ctrl.Result{}, nil
		}
		return ctrl.Result{}, err
	}

	// 检查必要的组件是否已初始化
	if r.Recorder == nil {
		log.Error(fmt.Errorf("event recorder not initialized"), "failed to record event")
		return ctrl.Result{}, fmt.Errorf("event recorder not initialized")
	}

	// Check the ingressClassName
	if ingress.Spec.IngressClassName != nil && *ingress.Spec.IngressClassName == "layer7" {
		log.Info(fmt.Sprintf("Processing Ingress with custom IngressClassName: %s", *ingress.Spec.IngressClassName))

		for _, rule := range ingress.Spec.Rules {
			host := rule.Host
			for _, path := range rule.HTTP.Paths {
				serviceName := path.Backend.Service.Name
				serviceNamespace := ingress.Namespace

				// 获取 Pod 列表
				var podList corev1.PodList
				if err := r.List(ctx, &podList,
					client.InNamespace(serviceNamespace),
					client.MatchingLabels(svc.Spec.Selector)); err != nil {
					continue
				}

				// 收集 Pod IPs
				var podIPs []string
				for _, pod := range podList.Items {
					if pod.Status.Phase == corev1.PodRunning {
						podIPs = append(podIPs, pod.Status.PodIP)
					}
				}

				// 记录事件
				r.Recorder.Event(ingress,
					corev1.EventTypeWarning,
					"Listing Pods",
					"success to get current pods list !")


			}
		}
	}

	return ctrl.Result{}, nil
}

// 创建索引器用于根据 Service 查找 Ingress
func (r *IngressReconciler) SetupWithManager(mgr ctrl.Manager) error {
	...
}

监控指标 metrics/metric.go

package metrics

import (
	"fmt"

	"github.com/prometheus/client_golang/prometheus"
	ctrl "sigs.k8s.io/controller-runtime"
	"sigs.k8s.io/controller-runtime/pkg/metrics"
)

const (
	Reconcile = "Reconcile"
)

var (
	// 添加一个初始化标志
	initialized bool
	log         = ctrl.Log.WithName("metrics")

	// ReconcileTotal 记录调谐次数
	ReconcileTotal = prometheus.NewCounterVec(
		prometheus.CounterOpts{
			Namespace: "layer7",
			Subsystem: "controller",
			Name:      "reconcile_total",
			Help:      "Number of reconcile",
		}, []string{"name"})
)

// InitMetrics 确保指标只被注册一次
func InitMetrics() {
	if !initialized {
		log.Info("Initializing metrics...")
		// 注册其他指标
		metricsToRegister := []prometheus.Collector{
			ReconcileTotal,
		}

		for _, m := range metricsToRegister {
			if err := metrics.Registry.Register(m); err != nil {
				log.Error(err, "Failed to register metric", "metric", fmt.Sprintf("%T", m))
				metrics.Registry.Unregister(m)
				metrics.Registry.MustRegister(m)
			}
		}

		initialized = true
		log.Info("Metrics initialized successfully")

	}
}

三、调试及验证

①vscode下launch.json文件配置环境变量:KUBECONFIG

{
    "version": "0.2.0",
    "configurations": [
        {
            "name": "layer7",
            "type": "go",
            "request": "launch",
            "mode": "debug",
            "program": "${workspaceFolder}/cmd/main.go",
            "cwd": "${workspaceFolder}/cmd",
            "env": {
                "KUBECONFIG": "/home/xxx/.kube/private-kube-config.conf"
            }
        }
    ]
}

②准备调试yaml（含deployment、service、ingress）

apiVersion: apps/v1
kind: Deployment
metadata:
  namespace: lb-layer7-demo
  name: lb-layer7-nginx-test-01
  labels:
    app: lb-layer7-nginx-test-01
spec:
  replicas: 1
  selector:
    matchLabels:
      app: lb-layer7-nginx-test-01
  template:
    metadata:
      labels:
        app: lb-layer7-nginx-test-01
    spec:
      containers:
      - name: nginx
        image: mirror.k8s.qihoo.net/docker/nginx:latest
        ports:
        - containerPort: 80
---
apiVersion: v1
kind: Service
metadata:
  namespace: lb-layer7-demo
  name: lb-layer7-nginx-test-01
  labels:
    app: lb-layer7-nginx-test-01
spec:
  ports:
  - protocol: TCP
    port: 80
    targetPort: 80
  selector:
    app: lb-layer7-nginx-test-01
---
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: lb-layer7-nginx-test
  namespace: lb-layer7-demo
spec:
  ingressClassName: layer7
  rules:
    - host: lb.layer7.test.com
      http:
        paths:
          - backend:
              service:
                name: lb-layer7-nginx-test-01
                port:
                  number: 80
            path: /
            pathType: Prefix

③创建命名空间及部署资源

$ kubectl create ns lb-layer7-demo
namespace/lb-layer7-demo created

$ kubectl apply -f lb-layer7.yaml
deployment.apps/lb-layer7-nginx-test-01 created
service/lb-layer7-nginx-test-01 created
ingress.networking.k8s.io/lb-layer7-nginx-test created

$ kubectl get deploy,svc,ing
NAME                                      READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/lb-layer7-nginx-test-01   1/1     1            1           2m26s

NAME                              TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)   AGE
service/lb-layer7-nginx-test-01   ClusterIP   172.24.105.41   <none>        80/TCP    2m26s

NAME                                             CLASS    HOSTS                ADDRESS   PORTS   AGE
ingress.networking.k8s.io/lb-layer7-nginx-test   layer7   lb.layer7.test.com             80      2m26s

④启动调试

⑤查看端口：8888

$ lsof -i:8888
COMMAND       PID        USER   FD   TYPE    DEVICE SIZE/OFF NODE NAME
__debug_b 3207798 shijianpeng    8u  IPv6 563094246      0t0  TCP *:ddi-tcp-1 (LISTEN)

⑥查看暴漏指标

$ curl -s http://localhost:8888/metrics | grep "layer7"
# HELP layer7_controller_reconcile_total Number of reconcile
# TYPE layer7_controller_reconcile_total counter
layer7_controller_reconcile_total{name="Reconcile"} 2
# HELP layer7_controller_sync_total Total number of layer7 configuration synchronizations
# TYPE layer7_controller_sync_total counter
layer7_controller_sync_total{host="lb.layer7.test.com",name="lb-layer7-nginx-test-01",namespace="lb-layer7-demo",reason="",status="success"} 1

三、镜像构建及推送

1、使用vendor模式构建镜像，修改Dockerfile

替换基础镜像：

sed -i 's#golang:1.22#swr.cn-north-4.myhuaweicloud.com/ddn-k8s/docker.io/golang:1.23.1#' Dockerfile
sed -i 's#gcr.io/distroless/static:nonroot#swr.cn-north-4.myhuaweicloud.com/ddn-k8s/gcr.io/distroless/static:nonroot#' Dockerfile

Dockerfile内容

# Build the manager binary
FROM swr.cn-north-4.myhuaweicloud.com/ddn-k8s/docker.io/library/golang:1.22.5 AS builder
ARG TARGETOS
ARG TARGETARCH

WORKDIR /workspace

# 复制整个项目目录
COPY . .

# 使用vendor模式构建
RUN CGO_ENABLED=0 GOOS=${TARGETOS:-linux} GOARCH=${TARGETARCH} go build -mod=vendor -a -o manager cmd/main.go

# 使用更小的基础镜像
FROM swr.cn-north-4.myhuaweicloud.com/ddn-k8s/gcr.io/distroless/static:nonroot
WORKDIR /
COPY --from=builder /workspace/manager .
USER 65532:65532

ENTRYPOINT ["/manager"]

2、构建镜像

$ go mod vendor
$ sudo docker build -t lb-controller/lb-layer7:v0.0.1 .
$ sudo docker images
REPOSITORY                  TAG       IMAGE ID       CREATED         SIZE
lb-controller/lb-layer7     v0.0.1    da64931a01d2   8 seconds ago   74.7MB

3、镜像tag标记

#标记镜像
$ sudo docker tag lb-controller/lb-layer7:v0.0.1 harbor.qihoo.net/lb-controller/lb-layer7:v0.0.1

4、镜像推送

#登录远程仓库
$ docker login harbor.qihoo.net/lb-controller
#推送
$ docker push harbor.qihoo.net/lb-controller/lb-layer7:v0.0.1

5、本地部署验证

#查看构建的镜像
$ sudo docker images
REPOSITORY                  TAG       IMAGE ID       CREATED         SIZE
lb-controller/lb-layer7     v0.0.1    da64931a01d2   8 seconds ago   74.7MB

#部署到当前集群
$ make deploy IMG=lb-controller/lb-layer7:v0.0.1

#验证
$ kubectl get svc,deploy,pod -n lb-layer7-system
NAME                                                   TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)    AGE
service/lb-layer7-controller-manager-metrics-service   ClusterIP   172.24.178.129   <none>        8443/TCP   7m15s

NAME                                           READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/lb-layer7-controller-manager   1/1     1            1           7m15s

NAME                                                READY   STATUS    RESTARTS   AGE
pod/lb-layer7-controller-manager-78d58db99d-wkvwb   1/1     Running   0          2m6s

# 卸载部署
$ make undeploy

三、使用helm构建chart

创建helm及变更配置

#创建
$ helm create lb-layer7

Chart.yaml

apiVersion: v2
name: lb-layer7
description: A Helm chart for Kubernetes
type: application
version: 0.0.1
appVersion: "v0.0.1"

values.yaml

replicaCount: 1

image:
  repository: harbor.qihoo.net/lb-controller/lb-layer7
  tag: v0.0.1
  pullPolicy: IfNotPresent

resources:
  limits:
    cpu: 500m
    memory: 256Mi
  requests:
    cpu: 250m
    memory: 128Mi

templates/deployment.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  name: {{ .Release.Name }}
  labels:
    app: {{ .Chart.Name }}
    release: {{ .Release.Name }}
spec:
  replicas: {{ .Values.replicaCount }}
  selector:
    matchLabels:
      app: {{ .Chart.Name }}
      release: {{ .Release.Name }}
  template:
    metadata:
      labels:
        app: {{ .Chart.Name }}
        release: {{ .Release.Name }}
    spec:
      containers:
        - name: {{ .Chart.Name }}
          image: "{{ .Values.image.repository }}:{{ .Values.image.tag }}"
          imagePullPolicy: {{ .Values.image.pullPolicy }}
          resources:
            {{- toYaml .Values.resources | nindent 12 }}

四、helm调试&安装&打包命令

#渲染 Chart 模板
$ helm template --debug ./lb-layer7

#调试安装或升级
$ helm install --debug --dry-run lb-layer7 ./lb-layer7 -n lb-layer7-system

#安装
$ helm install lb-layer7 ./lb-layer7

#查看状态
$ helm status  lb-layer7

#查看生成的完整的YAML
$ helm get manifest lb-layer7

#查看集群里安装的chart
$ helm list -A

#打包
$ helm package lb-layer7

#发布
$ helm push lb-layer7-0.0.1.tgz https://harbor.qihoo.net/chartrepo/xxx

#卸载
$ helm uninstall lb-layer7

五、部署controller注意:

①pod镜像私有仓库访问

#使用私有仓库时，首次拉取镜像无权限，创建一个secret
$ kubectl create secret docker-registry harbor-360 --namespace=lb-layer7-system \
--docker-server="https://harbor.qihoo.net" \
--docker-username=xxx \
--docker-password=xxx

#添加imagePullSecrets
$ kubectl patch deploy lb-layer7 -n lb-layer7-system --type='json' \
-p='[
  {"op": "add", "path": "/spec/template/spec/imagePullSecrets", "value": [{"name": "harbor-360"}]}
]'

#配置sa
$ kubectl patch deploy lb-layer7 -n lb-layer7-system --type='json' \
-p='[
  {"op": "replace", "path": "/spec/template/spec/serviceAccountName", "value": "lb-layer7"}
]'

②配置serviceaccount及rbac权限文件：sa.yaml

apiVersion: v1
kind: ServiceAccount
metadata:
  name: lb-layer7
  namespace: lb-layer7-system

---

apiVersion: v1
kind: Secret
metadata:
  name: lb-layer7-secret
  annotations:
    kubernetes.io/service-account.name: "lb-layer7"
type: kubernetes.io/service-account-token

---

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: lb-layer7
rules:
  - apiGroups: ["networking.k8s.io"]
    resources: ["ingresses"]
    verbs: ["get", "list", "watch"]
  - apiGroups: [""]
    resources: ["services"]
    verbs: ["get", "list", "watch"]
  - apiGroups: [""]
    resources: ["pods"]
    verbs: ["get", "list", "watch"]

---

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: lb-layer7-binding
subjects:
  - kind: ServiceAccount
    name: lb-layer7
    namespace: lb-layer7-system
roleRef:
  kind: ClusterRole
  name: lb-layer7
  apiGroup: rbac.authorization.k8s.io

③验证

$ kubectl apply -f sa.yaml

#验证ingress权限
$ kubectl auth can-i watch ingresses.networking.k8s.io --as=system:serviceaccount:lb-layer7-system:lb-layer7 --all-namespaces

#验证service权限
$ kubectl auth can-i list services --as=system:serviceaccount:lb-layer7-system:lb-layer7 --all-namespaces

#验证pods权限
$ kubectl auth can-i list pods --as=system:serviceaccount:lb-layer7-system:lb-layer7 --all-namespaces


#或者
$ kubectl describe clusterrole lb-layer7
$ kubectl describe clusterrolebinding lb-layer7-binding

总结

本篇从环境初始化到 Helm 部署，详细介绍了 Kubernetes 控制器的开发流程。通过实际操作，你应该掌握了以下关键技能：

如何使用 kubebuilder 创建控制器
监听 Kubernetes 资源并编写 Reconcile 逻辑
监控 Metrics 并优化性能
构建、推送镜像及 Helm 部署

掌握 Kubernetes 控制器开发，可以帮助你自动化集群管理，提高运维效率，并深入理解 Kubernetes 的工作原理。

上一篇：使用docker 和marathon 构建一个带分析的web应用
下一篇： Docker容器基于国产平台T3的入门部署方法说明——(3)构建镜像

网站首页 > 基础教程 正文

Kubernetes 控制器开发、镜像构建及部署实践

引言

一、初始化项目

二、核心代码编写

三、调试及验证

①vscode下launch.json文件配置环境变量:KUBECONFIG

②准备调试yaml（含deployment、service、ingress）

③创建命名空间及部署资源

④启动调试

⑤查看端口：8888

⑥查看暴漏指标

三、镜像构建及推送

1、使用vendor模式构建镜像，修改Dockerfile

2、构建镜像

3、镜像tag标记

4、镜像推送

5、本地部署验证

三、使用helm构建chart

四、helm调试&安装&打包命令

五、部署controller注意:

①pod镜像私有仓库访问

②配置serviceaccount及rbac权限文件：sa.yaml

③验证

总结

猜你喜欢

网站首页 > 基础教程正文
